Virtual Satellite Network Emulator System (VSNES)

The Virtual Satellite Network Emulator System (VSNES) is a Python-based tool designed to simulate satellite networks, including satellite orbits, ground stations, and communication channels. It provides tools for visualizing scenarios in Cesium, managing virtual machines (VMs) and containers for emulation, and propagating satellite orbits using TLE data. VSNES can be integrated into AI workflows by exposing a Model Context Protocol (MCP) server, enabling AI agents such as Claude to autonomously configure, launch, and monitor satellite network emulations.

---

What's New in v2.0

REST API (apiServer.py)

A new Flask-based REST API server runs on port 5050 alongside the Cesium visualization server, exposing the full emulator lifecycle over HTTP. This replaces the need for direct CLI interaction and enables integration with external tools, dashboards, and automation pipelines.

Key endpoints:

Method	Endpoint	Description
GET	/api/health	Health check
POST	/api/upload-config	Upload a TOML configuration file
POST	/api/upload-tle	Upload a TLE file
POST	/api/load-config	Load config.toml into the system
POST	/api/init-scenario	Initialize the scenario from loaded config
GET	/api/scenario	Get current scenario description
POST	/api/write-czml	Generate the CZML file for Cesium
POST	/api/start-vms	Start all VMs
POST	/api/stop-vm/<name>	Stop a specific VM
POST	/api/stop-all-vms	Stop all VMs
DELETE	/api/delete-vm/<name>	Delete a specific VM
DELETE	/api/delete-all-vms	Delete all VMs
POST	/api/compose/up	Start the Docker node containers (docker compose up -d); optional JSON body {"services": ["satellite-1", ...]} to start a subset
POST	/api/compose/down	Stop and remove the Docker node containers (docker compose down)
POST	/api/simulation/start	Start full emulation and visualization
POST	/api/visualization/start	Start visualization only
POST	/api/simulation/stop	Stop the running simulation
GET	/api/status	Get system status and simulation progress
POST	/api/reset	Stop simulation and reset all state
GET	/api/help	List all available endpoints

The API tracks system state across the lifecycle (IDLE → CONFIG_LOADED → SCENARIO_INIT → PREPARING_VMS → RUNNING_SIMULATION) and returns 409 Conflict responses for invalid transitions.

To start (launched automatically by SatelliteEmulator.py):

python SatelliteEmulator.py        # starts API + interactive CLI
python SatelliteEmulator.py --web  # API + Cesium web server

---

MCP Server (mcpServer.py)

A Model Context Protocol (MCP) server built with fastmcp, running on port 8560. It exposes the emulator and VM management as callable tools for AI agents (e.g., Claude Desktop, Claude Code).

Available tools:

Emulator Control (via REST API)

Tool	Description
prepare_simulation	Load config and initialize scenario
start_simulation	Start emulation and visualization
stop_simulation	Stop and reset the emulator
get_emulator_status	Get full system status
compose_up	Start the Docker node containers (optionally a list of service names)
compose_down	Stop and remove the Docker node containers

VM Management (direct Libvirt/SSH)

Tool	Description
list_vms	List all VMs (name, state, IP) via Libvirt
manage_vm_power	Start or stop a VM (or all VMs) via Libvirt
execute_vm_command	Run a shell command on a VM (or all VMs) via SSH

Configuration Generation (AI-assisted setup)

Tool	Description
get_config_guide	Returns a structured guide the AI uses to interview the user and collect scenario parameters
generate_config_toml	Generates a config.toml file from satellites, ground stations, channels, and time parameters
generate_docker_compose	Generates docker-compose.yml from a config file or explicit node list, optionally creating a Dockerfile

To start (launched automatically by SatelliteEmulator.py):

python SatelliteEmulator.py --mcp        # API + MCP
python SatelliteEmulator.py --all        # API + Web + NTP + MCP

Configure SSH credentials and API base URL via environment variables:

export SNES_API_URL=http://localhost:5050
export VM_SSH_USER=debian
export VM_SSH_PASS=debian

---

Simulation-Aware NTP Server (ntpserver.py)

A custom UDP NTP server that synchronizes VM clocks to the emulator's simulated time. It reads the current simulation timestamp from simulation_time.txt (updated by the emulator during runtime) and serves it to NTP clients. Falls back to system time if the file is unavailable.

# Default (port 123, requires root)
sudo python3 ntpserver.py

# Custom port (no root required)
python3 ntpserver.py --port 12345

The API server starts the NTP server automatically on port 12345.

---

Web Dashboard

A new browser-based control panel is served by the Cesium visualization server (Class/static/). It includes a custom design system with Orbitron and Lato fonts, icon set, and a responsive layout. The frontend communicates with the REST API to load configs, manage VMs, and control the simulation without using the CLI.

---

Structured Logging

All server components write structured logs to /tmp/log/snes.log with timestamps and severity levels, in addition to console output.

---

Features

• Orbit Propagation: Supports SGP4 and Two-Body models for satellite orbit propagation.
• Node Management: Handles satellites and ground stations as nodes in the network.
• Communication Channels: Simulates communication delays and properties between nodes.
• Visualization: Generates CZML files for Cesium-based 3D visualization.
• VM Management: Creates, starts, stops, and deletes virtual machines for emulation.
• Server Integration: Provides a Flask-based server for Cesium visualizations and API endpoints.
• REST API: Full HTTP API for programmatic control of the emulator lifecycle.
• MCP Server: AI-agent-friendly tool interface via the Model Context Protocol.
• Simulation NTP: Custom NTP server serving simulation time to emulated VMs.

---

Project Structure

1. Class/

Contains the core classes and modules for the emulator.

• Core Classes:

  • Node.py: Base class for all nodes (satellites and ground stations).
  • Orbit.py: Base class for handling satellite orbits using TLE data.
  • Scenario.py: Manages the overall emulation scenario.

• Extended Classes:

  • Satellite.py: Extends Node to represent satellites.
  • Ground_Station.py: Extends Node to represent ground stations.

• Orbit Propagation Models:

  • SGP4.py: Implements the SGP4 model for orbit propagation.
  • TwoBody.py: Implements a two-body model for orbit propagation.

• Communication and Channels:

  • Channel.py: Handles communication channels between nodes.
  • channel_threshold.py: Defines thresholds and parameters for channel configurations.

• Time Management:

  • Time_parameters.py: Manages time-related settings for the emulation.

• Server and Visualization:

  • Server.py: Flask server for Cesium visualization (port 5500).
  • static/: Web dashboard assets (CSS, JS, fonts, icons).
  • templates/: HTML and CZML templates for Cesium.

---

2. SatelliteEmulator.py

Interactive CLI entry point. Talks to the REST API to load configs, manage VMs, generate CZML, and launch or stop the simulation.

---

3. apiServer.py

REST API server (port 5050). Exposes the full emulator lifecycle over HTTP. Also starts the Cesium visualization server and the NTP server automatically on launch.

---

4. mcpServer.py

MCP server (port 8560). Exposes emulator control, VM management, and configuration generation as AI-callable tools. Enables full integration with AI agents such as Claude Desktop or Claude Code.

---

5. ntpserver.py

Simulation-aware NTP server. Serves emulator simulation time to nodes in the emulated network.

---

6. docker-compose.yml

Defines all satellite and ground station containers for Docker-based deployments on the vsnes_net (172.27.12.0/24) bridge network.

---

7. docker/

• Dockerfile: Debian 12 image with SSH, networking tools, and k3s pre-installed.
• entrypoint.sh: Container startup script.

---

8. config.toml

Configuration file defining the scenario: nodes, channels, time parameters, and network settings.

---

Installation

Follow these steps to set up VSNES on your machine:

1. System Requirements

• Linux-based operating system (tested on Ubuntu).
• Python 3.10 or later.
• Virtualization support (QEMU/KVM).

---

2. Install Required Packages

sudo install.sh

3. Fix for czml Library

The czml library requires a small fix. Open the file:

sudo nano /usr/local/lib/python3.10/dist-packages/czml/czml.py

Note: Find the exact path with pip3 show czml

Replace:

from pygeoif.geometry import as_shape as asShape

With:

from pygeoif.factories import shape as asShape

---

Usage

CLI Mode

SatelliteEmulator.py is the single entry point. It always starts apiServer.py internally and drops into an interactive CLI once the API is ready. Optional flags control which additional services start alongside it.

python SatelliteEmulator.py              # API only
python SatelliteEmulator.py --web        # API + Cesium web server (port 5580)
python SatelliteEmulator.py --ntp        # API + NTP server (port 12345)
python SatelliteEmulator.py --mcp        # API + MCP server (port 8560)
python SatelliteEmulator.py --all        # API + Web + NTP + MCP
python SatelliteEmulator.py --web --mcp  # combine any flags

Services started and their addresses:

Service	Address	Flag
REST API	http://localhost:5050	always
Cesium GUI	http://localhost:5580	--web
NTP server	port 12345	--ntp
MCP server	http://localhost:8560	--mcp

Available interactive commands:

Command	Aliases	Description
help		Show all available actions
load_scenario	load	Load config.toml and initialize the scenario
scenario		Display loaded nodes and their types
start_vms	vm	Create or start containers/VMs for all nodes
compose_up [services...]	compose up	Start the Docker node containers via the API (docker compose up -d); optionally name specific services, e.g. compose_up satellite-1 ibi_es
compose_down	compose down	Stop and remove the Docker node containers via the API (docker compose down)
write_czml		Generate ScenarioCZML.czml for Cesium
run_all	run	Run full emulation and Cesium visualization
run_emulator	emu, emulator, run_emu	Run emulation only (no Cesium)
run_cesium	cesium	Run Cesium visualization only
stop		Stop the running simulation
shutdown_vms		Shut down all nodes
delete_vm	delete	Delete a specific VM or all VMs
exit		End the program (prompts to delete VMs)

API Mode

python SatelliteEmulator.py --web

• REST API: http://localhost:5050
• Cesium GUI: http://localhost:5580
• API docs: http://localhost:5050/api/help

Typical workflow:

# 1. Upload files
curl -F "file=@config.toml" http://localhost:5050/api/upload-config
curl -F "file=@sample.tle"  http://localhost:5050/api/upload-tle

# 2. Start the Docker node containers (all, or a subset of services)
curl -X POST http://localhost:5050/api/compose/up
curl -X POST -H "Content-Type: application/json" \
     -d '{"services": ["satellite-1", "satellite-2", "satellite-3", "ibi_es"]}' \
     http://localhost:5050/api/compose/up

# 3. Load and initialize
curl -X POST http://localhost:5050/api/load-config
curl -X POST http://localhost:5050/api/init-scenario

# 4. Start simulation
curl -X POST http://localhost:5050/api/simulation/start

# 5. Monitor
curl http://localhost:5050/api/status

# 6. Stop
curl -X POST http://localhost:5050/api/simulation/stop

# 7. Tear down the containers
curl -X POST http://localhost:5050/api/compose/down

MCP Mode (AI Integration)

The MCP server connects an AI agent directly to VSNES, allowing it to configure, launch, and monitor satellite network emulations through natural language.

python SatelliteEmulator.py --mcp        # API + MCP
python SatelliteEmulator.py --all        # API + Web + NTP + MCP

Configure the server via environment variables:

export SNES_API_URL=http://localhost:5050   # REST API address
export VM_SSH_USER=debian                   # SSH user for VMs
export VM_SSH_PASS=debian                   # SSH password for VMs

To connect from Claude Desktop, add the following to your claude_desktop_config.json:

{
  "mcpServers": {
    "vsnes": {
      "url": "http://localhost:8560/mcp"
    }
  }
}

Typical AI-driven workflow:

1. AI calls get_config_guide to learn what parameters to collect
2. AI interviews the user and calls generate_config_toml to write config.toml
3. AI calls generate_docker_compose to create the container manifest
4. AI calls prepare_simulation → start_simulation to launch the emulation
5. AI monitors progress with get_emulator_status and stops with stop_simulation

---

Configuration File

The configuration file (config.toml) defines the parameters for VSNES. Below is a detailed explanation of each section:

---

1. Network Configuration

• network: Specifies the subnet for the emulated network (in CIDR notation).
• network_ext: Specifies the subnet of the network which hosts the external domains/VMs in the Relay mode (in CIDR notation).
• unicast_flooding: If 1, the virtual switch of brSATEMU will not logically map MAC addresses with ports. This means that all the traffic received from one port will be broadcasted to all the other ports. If 0, the virtual switch will map MAC addresses and forward traffic only to the correct destination port.

---

2. Time Configuration

• TimeInterval: Time step for the simulation in minutes.
• Contact_speed: Speed multiplier for contact periods.
• Non_contact_speed: Speed multiplier for non-contact periods.
• start_datetime: Start time of the simulation in YYYY-MM-DD HH:MM:SS format.
• end_datetime: End time of the simulation in YYYY-MM-DD HH:MM:SS format.

---

3. Space Segment (Satellites)

• TLE: Path to the TLE file containing satellite orbital data.
• SatelliteSistem: Defines individual satellites.
  • propagator: Orbit propagation model (SGP4 or TwoBody).
  • Service: Satellite service type (Standard or Relay).
  • name: Name of the satellite.
  • group: Group name (e.g., LEO for Low Earth Orbit).
  • OS: Operating system of the satellite's VM (ubuntu or alpine).
  • username: Username for the VM.
  • password: Password for the VM.
  • isVM: Indicates if the satellite is a virtual machine (1 for true, 0 for false).
  • ip_ext: External IP address of the VM.
  • interface: Network interface name.
  • clone_VM: Configuration for cloning the VM.
    • name_VM: Name of the base VM to clone.

---

4. Ground Segment (Ground Stations)

• GroundSistem: Defines individual ground stations.
  • name: Name of the ground station.
  • group: Group name (e.g., GS for Ground Station).
  • latitude: Latitude of the ground station in degrees.
  • longitude: Longitude of the ground station in degrees.
  • height: Height of the ground station above sea level in meters.
  • OS: Operating system of the ground station's VM (ubuntu or alpine).
  • username: Username for the VM.
  • password: Password for the VM.
  • interface: Network interface name.
  • clone_VM: Configuration for cloning the VM.
    • name_VM: Name of the base VM to clone.

---

5. Channels (Communication Links)

• Channel: Defines communication links between nodes.
  • Node1: Group name of the first node (e.g., LEO for satellites).
  • Node2: Group name of the second node (e.g., GS for ground stations).
  • Min_elevation_angle: Minimum elevation angle for the link in degrees.
  • Threshold: Maximum distance for the link in meters.
  • Data_rate: Data rate of the link in Mbit/s.
  • Packet_loss: Percentage of packet loss for the link.
  • Correlated_losses: Percentage of correlated packet losses (e.g., burst losses).

---

Notes

• Ensure that the TLE file specified in the SpaceSegment section exists and contains valid TLE data. sample.tle contains a sample TLE file.
• The clone_VM section is optional and only required if you are cloning virtual machines for the emulation.
• The Channels section allows you to define multiple communication links between nodes.
• libvirt implements DHCP, so if you want to avoid modifying the configuration of each VM to allocate a static IP:
  • Get the MAC address of the VM: $ virsh domiflist <VM_name>
  • Apply the DHCP rule: $ virsh net-edit default

  <dhcp>
  ...
  <host mac="<VM_MAC>" name="VM_name" ip="<VM_static_IP>"/>

  • Restart the network, in this example default: $ virsh net-destroy default and $ virsh net-start default
  • Reboot the VM: $ virsh shutdown <VM_name> and $ virsh start <VM_name>
• Be careful if a kernel-level VPN is up in the host, as it will affect the routing table and make VMs not reachable. In that case, consider disabling the VPN.

Other tools

Libvirt Dashboard

Libvirt Dashboard utilizes Prometheus to visualize metrics of VMs in Grafana.

0. Install Prometheus and Grafana

Install Prometheus

$ sudo apt install prometheus

$ sudo systemctl status prometheus

Install Grafana

$ sudo apt-get install -y apt-transport-https software-properties-common wget

$ sudo mkdir -p /etc/apt/keyrings/

$ echo "deb [signed-by=/etc/apt/keyrings/grafana.gpg] https://apt.grafana.com stable main" | sudo tee -a /etc/apt/sources.list.d/grafana.list

$ echo "deb [signed-by=/etc/apt/keyrings/grafana.gpg] https://apt.grafana.com beta main" | sudo tee -a /etc/apt/sources.list.d/grafana.list

$ sudo apt-get update

$ sudo apt-get install grafana

$ sudo systemctl daemon-reload

$ sudo systemctl start grafana-server

$ sudo systemctl enable grafana-server

$ sudo systemctl status grafana-server

1. Install prometheus-libvirt-exporter

Install prometheus-libvirt-exporter (https://github.com/zhangjianweibj/prometheus-libvirt-exporter)

$ sudo apt install golang-go

$ go install github.com/goreleaser/goreleaser@latest

$ go install github.com/go-task/task/v3/cmd/task@latest

$ git clone https://github.com/zhangjianweibj/prometheus-libvirt-exporter.git

$ cd prometheus-libvirt-exporter/

$ go mod tidy

$ go mod vendor

$ go build ./...

$ go build

Configure Prometheus

$ nano /etc/prometheus/prometheus.yml

At the end of the file /etc/prometheus/prometheus.yml (within scrape_configs:), add the following:

  - job_name: 'libvirt_exporter'
    static_configs:
      - targets: ['localhost:9000']

$ sudo systemctl restart prometheus

2. Add prometheus-libvirt-exporter to Grafana

Add a new data source connection of type Prometheus to Grafana. Include http://localhost:9090 as the connection URL.

3. Import the dashboard

Download or copy the dashboard in JSON: https://grafana.com/grafana/dashboards/15682-libvirt/

Import or paste it in Grafana

4. Run prometheus-libvirt-exporter

Run prometheus-libvirt-exporter to start capturing metrics (Grafana will visualize them automatically)

$ cd prometheus-libvirt-exporter

$ ./prometheus-libvirt-exporter

Source

Developed within i2-22-RDI-IoT A2 DSS Sim. Aquest projecte ha rebut finançament per part del Govern de la Generalitat de Catalunya dins del marc de l'estrategia NewSpace a Catalunya.

Copyright

Developed by Fundació Privada Internet i Innovació Digital a Catalunya (i2CAT). Find more information at https://i2cat.net/tech-transfer/

Licence

Licensed under the GNU AFFERO GENERAL PUBLIC LICENSE. See https://www.gnu.org/licenses/agpl-3.0.en.html.

For licensing enquiries: techtransfer@i2cat.net
