Added `make prepare` before Phase 1 `make modules` by opencode-agent[bot] · Pull Request #27 · dianlight/hasos_more_modules

opencode-agent · 2026-06-16T22:13:28Z

Fix applied: Added an explicit make prepare step before make modules in Phase 1 (base module build) of the workflow.

Analysis of the failure (workflow run #148):

All RPi-based boards (rpi3_64, rpi4_64, rpi5_64, yellow) failed at the "Build base modules" step
All other non-RPi boards succeeded
The RPi kernel fork at 6.18.33 (commit 95b85bebbedc) has different build infrastructure from mainline 6.18.35 used by other boards
Phase 2 already had an explicit make prepare call for ZFS compatibility, but Phase 1 was missing it

The fix adds make prepare before make modules in .github/workflows/main_build.yml:436-441, ensuring the kernel source tree generates all required build artifacts (utsrelease.h, autoconf.h, architecture-specific headers, etc.) before module compilation. This follows the same pattern already established in Phase 2 for ZFS module building.

Closes #26

opencode session | github run

Co-authored-by: dianlight <dianlight@users.noreply.github.com>

github-actions · 2026-06-16T22:13:47Z

User opencode-agent[bot] does not have write permissions

github run

dianlight · 2026-06-17T12:32:30Z

/oc I have still an error for rpi. See run #150. You can also try yourself until all is ok

Key changes: - Phase 1: Use MODULE_CROSS_COMPILE (Buildroot toolchain) for both make modules_prepare and make modules, instead of mixing system and Buildroot toolchains - Phase 2 QUIC: Add make modules_prepare before make modules after source patching - Phase 2 ZFS: Resolve MODULE_CROSS_COMPILE earlier and use consistently throughout the step - All phases: Use modules_prepare (which generates module.lds) instead of bare prepare for module build preparation

opencode-agent · 2026-06-17T20:44:58Z

Pushed commit 54464c5 to the PR branch. Here's what changed and why:

Root cause analysis: Only RPi boards (rpi3_64, rpi4_64, rpi5_64, yellow) fail in Phase 1 "Build base modules" — all other arm64 boards succeed. The RPi kernel fork at 6.18.33 (vs mainline 6.18.35) has a different prepare target that builds VDSO via cross-compilation. The previous fix ran make prepare with the system cross compiler (aarch64-linux-gnu-) while make modules used the Buildroot cross compiler (aarch64-buildroot-linux-gnu-). This toolchain mismatch caused the VDSO build to fail on the RPi fork.

Changes made (.github/workflows/main_build.yml):

Phase 1 — make prepare → make modules_prepare with MODULE_CROSS_COMPILE (Buildroot toolchain), same as make modules
Phase 2 QUIC — Added make modules_prepare after source patching, before make modules
Phase 2 ZFS — Moved MODULE_CROSS_COMPILE resolution before make prepare; use it consistently for prepare, olddefconfig, modules_prepare, and modules

opencode session | github run

github-actions · 2026-06-17T20:45:01Z

User opencode-agent[bot] does not have write permissions

github run

opencode-agent · 2026-06-17T20:45:25Z

User opencode-agent[bot] does not have write permissions

github run

github-actions · 2026-06-18T13:23:08Z

PR Review: #27

Changes Summary

Adds make modules_prepare before make modules in all 3 phases (base, QUIC, ZFS) and switches ZFS from CROSS_COMPILE to MODULE_CROSS_COMPILE (Buildroot toolchain) for prepare and olddefconfig.

Code Quality Issues

DRY violation — MODULE_CROSS_COMPILE resolution block (the case "${ARCH}" + [[ -x ... ]] fallback) is copy-pasted 3 times (Phase 1 at line ~475, QUIC at line ~561, ZFS at line ~611). Extract to a composite action or set it as a job-level env once.
Minor inconsistency — Phase 1 base modules lack KBUILD_MODPOST_WARN=1 while QUIC and ZFS have it. Pre-existing, but worth noting since it could cause CI divergence.

Potential Bugs

No || true on modules_prepare — with set -euo pipefail, a failure on any board/arch kills the step. modules_prepare can fail on kernels with unusual build setups. Consider graceful handling.
modules_prepare after make prepare in ZFS is redundant — make prepare is a superset of modules_prepare. Not a bug, but unnecessary work. You could drop the second modules_prepare in the ZFS phase since prepare already ran. (Though it's harmless — it'll be a no-op.)

Suggestions

De-duplicate toolchain resolution — add a setup step like:

- name: Resolve Buildroot cross-compiler
  run: |
    case "${ARCH}" in
      arm64) echo "MODULE_CROSS_COMPILE=${OS_DIR}/output/host/bin/aarch64-buildroot-linux-gnu-" >> $GITHUB_ENV ;;
      x86)   echo "MODULE_CROSS_COMPILE=${OS_DIR}/output/host/bin/x86_64-buildroot-linux-gnu-" >> $GITHUB_ENV ;;
      *)     echo "MODULE_CROSS_COMPILE=${CROSS_COMPILE}" >> $GITHUB_ENV ;;
    esac
    [[ -x "${MODULE_CROSS_COMPILE}gcc" ]] || echo "MODULE_CROSS_COMPILE=${CROSS_COMPILE}" >> $GITHUB_ENV

In ZFS, drop the second modules_prepare — make prepare at line ~621 already generates all module build artifacts. The modules_prepare at line ~683 is a no-op after prepare.
Consider make scripts instead of modules_prepare — modules_prepare runs make scripts + generates Module.symvers. If you've already run make prepare, make scripts alone is sufficient and faster.

Verdict

The changes are correct and address the root cause (cross-compiler mismatch on RPi's 6.18.33 fork). The core fix — using the Buildroot MODULE_CROSS_COMPILE consistently for all make targets — is sound. The additions of modules_prepare are correct in spirit (Phase 1 and QUIC) though slightly redundant in ZFS.

Approved with suggestions above for follow-up cleanup.

opencode session | github run

github-actions · 2026-06-18T13:34:02Z

🛠️ [QUALITY] DRY violation — Cross-compiler resolution block copy-pasted 3 times

The MODULE_CROSS_COMPILE resolution logic (OS_DIR=... + case "${ARCH}" + [[ -x ... ]] fallback) is duplicated verbatim at:

Phase 1 (line 474-484)
Phase 2 QUIC (line 561-567)
Phase 2 ZFS (line 611-617)

If the path, architecture list, or fallback logic changes, all three must be updated in lockstep. Extract this into a job-level step or a composite action once, and export MODULE_CROSS_COMPILE to $GITHUB_ENV.

# Add as a dedicated step before the first build step
- name: Resolve Buildroot cross-compiler
  run: |
    OS_DIR="${GITHUB_WORKSPACE}/operating-system"
    case "${ARCH}" in
      arm64) MCC="${OS_DIR}/output/host/bin/aarch64-buildroot-linux-gnu-" ;;
      x86)   MCC="${OS_DIR}/output/host/bin/x86_64-buildroot-linux-gnu-" ;;
      *)     MCC="${CROSS_COMPILE}" ;;
    esac
    [[ -x "${MCC}gcc" ]] || MCC="${CROSS_COMPILE}"
    echo "MODULE_CROSS_COMPILE=${MCC}" >> "$GITHUB_ENV"

Then remove the three inline blocks and reference ${{ env.MODULE_CROSS_COMPILE }} or $MODULE_CROSS_COMPILE directly.

🛠️ [QUALITY] modules_prepare after prepare in ZFS phase is a no-op

At line 620-625 you run make prepare, which is a superset of modules_prepare (it generates all the same headers + basic kernel build artifacts). The modules_prepare at line 683-688 does nothing after prepare — the kernel build system detects it's already done and returns immediately. While harmless, it adds ~4 seconds of unnecessary output and could confuse future readers. Either drop it (since prepare already ran), or drop the earlier prepare if only module artifacts are needed.

🚨 [CRITICAL] set -euo pipefail without fallback on modules_prepare

All three modules_prepare invocations (lines 487, 570, 684) run under set -euo pipefail. If modules_prepare fails on an exotic kernel fork (e.g., an RPi variant with incomplete Kbuild), it will abort the entire step, including for other architectures in a matrix that would have succeeded. Consider adding || true with a diagnostic, or wrapping it:

echo "[INFO] Running 'make modules_prepare' ..."
make -C "${LINUX_SRC}" \
  ARCH="${ARCH}" \
  CROSS_COMPILE="${MODULE_CROSS_COMPILE}" \
  modules_prepare \
  2>&1 | tail -60 || echo "[WARN] modules_prepare exited non-zero, continuing"

This is the pattern already implied by | tail -XX (pipe absorbs non-zero exit) — but since set -o pipefail is active, a make failure still propagates.

💡 [NITPICK] Minor: extra blank line inconsistency between Phase 1 and Phase 2

Phase 1 has a blank line before the echo "[INFO] Building..." comment (line 493), but the QUIC phase does not (line 576 directly follows 2>&1 | tail -60). Add a blank line before line 576 for visual consistency with the other two phases.

Summary: The core fix (using MODULE_CROSS_COMPILE with Buildroot toolchain for all make targets in ZFS, and adding modules_prepare to Phase 1 and QUIC) is correct and targets the root cause. The main improvement is de-duplicating the toolchain resolution, which is a safety issue for future maintenance.

opencode session | github run

…into opencode/issue26-20260616220319

Why this change was needed: The previous dedup step removed rp1-cfe/ and patched the parent Makefile, but left the parent Kconfig untouched. olddefconfig parses Kconfig files before any compilation starts, so it died with "can't open file rp1-cfe/Kconfig" on all three RPi boards (rpi3_64, rpi4_64, rpi5_64). What changed: Added sed -i '/rp1-cfe/d' on the parent Kconfig alongside the existing Makefile patch, and updated the log message accordingly. Problem solved: All RPi board builds no longer fail with "can't open file" during olddefconfig when both rp1-cfe/ and rp1_cfe/ co-exist in the kernel tree. Co-Authored-By: Claude <noreply@anthropic.com>

github-actions · 2026-06-18T14:26:27Z

Here is my review of the PR changes across the three phases in .github/workflows/main_build.yml.

🛠️ [QUALITY] DRY violation — Cross-compiler resolution block copy-pasted 3 times

The MODULE_CROSS_COMPILE resolution logic (OS_DIR=... + case "${ARCH}" + [[ -x ... ]] fallback) is duplicated verbatim at:

Phase 1 (lines 514–523)
Phase 2 QUIC (lines 600–606)
Phase 2 ZFS (lines 649–656)

If the path, arch list, or fallback logic ever changes, all three must be updated in lockstep. Extract once into a dedicated step and export to $GITHUB_ENV:

      # ─────────────────────────────────────────────────────────────────────
      # Resolve Buildroot cross-compiler once for all build phases
      # ─────────────────────────────────────────────────────────────────────
      - name: Resolve Buildroot cross-compiler
        if: steps.precheck.outputs.should_build == 'true'
        env:
          ARCH: ${{ steps.arch.outputs.ARCH }}
          CROSS_COMPILE: ${{ steps.arch.outputs.CROSS_COMPILE }}
        run: |
          OS_DIR="${GITHUB_WORKSPACE}/operating-system"
          case "${ARCH}" in
            arm64) MCC="${OS_DIR}/output/host/bin/aarch64-buildroot-linux-gnu-" ;;
            x86)   MCC="${OS_DIR}/output/host/bin/x86_64-buildroot-linux-gnu-" ;;
            *)     MCC="${CROSS_COMPILE}" ;;
          esac
          [[ -x "${MCC}gcc" ]] || MCC="${CROSS_COMPILE}"
          echo "MODULE_CROSS_COMPILE=${MCC}" >> "$GITHUB_ENV"

Then remove the three inline resolution blocks and replace them with a plain echo "[INFO] Module build CROSS_COMPILE=${MODULE_CROSS_COMPILE}" (the env var is already available from the job environment).

🛠️ [QUALITY] modules_prepare after prepare in ZFS phase is a superset no-op

At line 659–664 you run make prepare, which is a superset of modules_prepare (it generates all the same headers, autoconf.h, utsrelease.h, plus arch-specific build artifacts). The second modules_prepare at lines 722–727 does nothing — the kernel build system detects everything is up to date and returns immediately. Drop it (it is ~4 seconds of unnecessary noise per ZFS build):


          make -C "${LINUX_SRC}" \
            ARCH="${ARCH}" \
            CROSS_COMPILE="${MODULE_CROSS_COMPILE}" \
            olddefconfig \
            2>&1 | tail -30

          echo "[INFO] Building ZFS kernel modules ..."
          make -C "${LINUX_SRC}" \
            ARCH="${ARCH}" \
            KBUILD_MODPOST_WARN=1 \
            CROSS_COMPILE="${MODULE_CROSS_COMPILE}" \
            modules \
            2>&1 | tail -100

          echo "[INFO] ZFS module built successfully."

(Alternatively, keep modules_prepare and drop the earlier prepare if ZFS configure only needs module-level headers. The PR description says ZFS configure needs utsrelease.h from make prepare, so keep prepare and drop modules_prepare.)

🚨 [CRITICAL] set -euo pipefail with no fallback on modules_prepare

All three modules_prepare invocations (lines 525–530, 608–613, 722–727) run under set -euo pipefail. If modules_prepare fails on an exotic kernel fork (e.g., a future RPi variant with incomplete Kbuild), it aborts the entire step for that board. The | tail -60 does not absorb failure because set -o pipefail propagates the make exit code.

Add a diagnostic fallback to continue when modules_prepare fails (the modules build will fail independently with a clearer error if headers are genuinely missing):

          echo "[INFO] Running 'make modules_prepare' for kernel module build ..."
          make -C "${LINUX_SRC}" \
            ARCH="${ARCH}" \
            CROSS_COMPILE="${MODULE_CROSS_COMPILE}" \
            modules_prepare \
            2>&1 | tail -60 || echo "[WARN] modules_prepare exited non-zero, continuing"

Apply the same pattern to the QUIC (line 608–613) and ZFS (line 722–727) phases.

💡 [NITPICK] Inconsistent fallback style for [[ -x ... ]] check

Phase 1 (lines 520–522) uses an if block, while QUIC (line 606) and ZFS (line 656) use || short-circuit. They are functionally identical but look different. Standardize on the shorter || form (or if form) across all three for consistency.

💡 [NITPICK] Missing blank line before QUIC echo

Phase 1 (line 525) and ZFS (line 659) have a blank line before the echo "[INFO] Running ...", but QUIC (line 608) does not. Add one for visual consistency:


          echo "[INFO] Running 'make modules_prepare' for QUIC module build ..."

Summary: The core fix — using the Buildroot MODULE_CROSS_COMPILE consistently for all make targets across all three phases — is correct and directly addresses the RPi toolchain mismatch. The three suggestions above are non-blocking refinements (DRY extraction, removing the redundant modules_prepare in ZFS, and hardening modules_prepare against set -e failures).

opencode session | github run

…into opencode/issue26-20260616220319

Why this change was needed: The heredoc pattern used to capture github.event.pull_request.body placed a ${{ }} expression and the PR_BODY_EOF delimiter at column 0 inside the run: | block. YAML block scalars terminate at any line with lower indentation than the block content, so the parser saw those lines as outside the scalar and raised a syntax error on line 81. What changed: PR_BODY is now declared in the step's env: map as PR_BODY: ${{ github.event.pull_request.body }} and the run: script reads it directly from the environment variable. The heredoc and its delimiters are gone entirely. Problem solved: The workflow file is valid YAML again. GitHub Actions safely handles multi-line PR body values (newlines, special chars) through env vars without any YAML quoting issues. Co-Authored-By: Claude <noreply@anthropic.com>

github-actions · 2026-06-18T14:31:32Z

Here is my review of the PR changes across .github/workflows/main_build.yml.

🛠️ [QUALITY] Cross-compiler resolution block copy-pasted 3 times

The MODULE_CROSS_COMPILE resolution logic is duplicated verbatim at:

Phase 1 (lines 514–523)
Phase 2 QUIC (lines 601–607)
Phase 2 ZFS (lines 650–657)

If the path, arch list, or fallback logic changes, all three must be updated in lockstep. Extract this once into a dedicated step before Phase 1 and export to $GITHUB_ENV. Then replace the three inline blocks with a simple echo that references the already-set env var.

      # ─────────────────────────────────────────────────────────────────────
      # Resolve Buildroot cross-compiler (shared by all build phases)
      # ─────────────────────────────────────────────────────────────────────
      - name: Resolve Buildroot cross-compiler
        if: steps.precheck.outputs.should_build == 'true'
        env:
          ARCH: ${{ steps.arch.outputs.ARCH }}
          CROSS_COMPILE: ${{ steps.arch.outputs.CROSS_COMPILE }}
        run: |
          OS_DIR="${GITHUB_WORKSPACE}/operating-system"
          case "${ARCH}" in
            arm64) MCC="${OS_DIR}/output/host/bin/aarch64-buildroot-linux-gnu-" ;;
            x86)   MCC="${OS_DIR}/output/host/bin/x86_64-buildroot-linux-gnu-" ;;
            *)     MCC="${CROSS_COMPILE}" ;;
          esac
          [[ -x "${MCC}gcc" ]] || MCC="${CROSS_COMPILE}"
          echo "MODULE_CROSS_COMPILE=${MCC}" >> "$GITHUB_ENV"
          echo "[INFO] Module build CROSS_COMPILE=${MCC}"

      # ─────────────────────────────────────────────────────────────────────
      # Phase 1: Build base modules (no kernel source patching required)
      # ─────────────────────────────────────────────────────────────────────
      - name: Build base modules (xfs, nfsd, nfs)
        if: steps.precheck.outputs.should_build == 'true'
        env:
          ARCH: ${{ steps.arch.outputs.ARCH }}
          CROSS_COMPILE: ${{ steps.arch.outputs.CROSS_COMPILE }}
        run: |
          set -euo pipefail
          # ... (same logic up to olddefconfig) ...

          echo "[INFO] Module build CROSS_COMPILE=${MODULE_CROSS_COMPILE}"

          echo "[INFO] Running 'make modules_prepare' for kernel module build ..."
          make -C "${LINUX_SRC}" \
            ARCH="${ARCH}" \
            CROSS_COMPILE="${MODULE_CROSS_COMPILE}" \
            modules_prepare \
            2>&1 | tail -60
          # ... rest of Phase 1 ...

Then remove the three inline resolution blocks (lines 514–523, 601–607, 650–657) and replace them with just echo "[INFO] Module build CROSS_COMPILE=${MODULE_CROSS_COMPILE}".

💡 [NITPICK] Inconsistent fallback style for toolchain check

Phase 1 (lines 521–523) uses an if block, while QUIC (line 607) and ZFS (line 657) use || short-circuit. Functionally identical but inconsistent when reading across phases. Standardize on the terser || form:

          [[ -x "${MODULE_CROSS_COMPILE}gcc" ]] || MODULE_CROSS_COMPILE="${CROSS_COMPILE}"

Apply to lines 521–523 in Phase 1.

💡 [NITPICK] Missing blank line before QUIC modules_prepare echo

Phase 1 (line 526) and ZFS (line 723) have a blank line before the echo "[INFO] Running 'make modules_prepare'...", but the QUIC section (line 609) does not.


          echo "[INFO] Running 'make modules_prepare' for QUIC module build ..."

Insert a blank line before line 609 for visual consistency.

Summary: The core fix — consistently using the Buildroot MODULE_CROSS_COMPILE across all make targets in all three phases — is correct and directly addresses the RPi toolchain mismatch that caused the VDSO build failure. The three items above are non-blocking follow-up refinements.

opencode session | github run

Added make prepare before Phase 1 make modules

7eeca6d

Co-authored-by: dianlight <dianlight@users.noreply.github.com>

opencode-agent Bot mentioned this pull request Jun 16, 2026

RPi kernel issue on 18-rc #26

Closed

Merge branch 'main' into opencode/issue26-20260616220319

dc07710

Merge branch 'main' into opencode/issue26-20260616220319

0852428

dianlight and others added 2 commits June 18, 2026 16:10

Merge branch 'main' of https://github.com/dianlight/hasos_more_modules …

0a0fb0b

…into opencode/issue26-20260616220319

dianlight and others added 2 commits June 18, 2026 16:27

Merge branch 'main' of https://github.com/dianlight/hasos_more_modules …

4ecf32e

…into opencode/issue26-20260616220319

dianlight merged commit 484932e into main Jun 18, 2026
9 checks passed

dianlight deleted the opencode/issue26-20260616220319 branch June 18, 2026 18:52

opencode-agent Bot mentioned this pull request Jun 23, 2026

Freshness & merge collision fix. #31

Open

Provide feedback

Saved searches

Use saved searches to filter your results more quickly

Uh oh!

Added `make prepare` before Phase 1 `make modules`#27

Added `make prepare` before Phase 1 `make modules`#27
dianlight merged 8 commits into
mainfrom
opencode/issue26-20260616220319

opencode-agent Bot commented Jun 16, 2026

Uh oh!

github-actions Bot commented Jun 16, 2026

Uh oh!

dianlight commented Jun 17, 2026

Uh oh!

opencode-agent Bot commented Jun 17, 2026

Uh oh!

github-actions Bot commented Jun 17, 2026

Uh oh!

opencode-agent Bot commented Jun 17, 2026

Uh oh!

github-actions Bot commented Jun 18, 2026

Uh oh!

github-actions Bot commented Jun 18, 2026

Uh oh!

github-actions Bot commented Jun 18, 2026

Uh oh!

github-actions Bot commented Jun 18, 2026

Uh oh!

Uh oh!

Reviewers

Assignees

Labels

Projects

Milestone

Development

Uh oh!

1 participant

Uh oh!

Conversation

opencode-agent Bot commented Jun 16, 2026

Uh oh!

github-actions Bot commented Jun 16, 2026

Uh oh!

dianlight commented Jun 17, 2026

Uh oh!

opencode-agent Bot commented Jun 17, 2026

Uh oh!

github-actions Bot commented Jun 17, 2026

Uh oh!

opencode-agent Bot commented Jun 17, 2026

Uh oh!

github-actions Bot commented Jun 18, 2026

PR Review: #27

Changes Summary

Code Quality Issues

Potential Bugs

Suggestions

Verdict

Uh oh!

github-actions Bot commented Jun 18, 2026

Uh oh!

github-actions Bot commented Jun 18, 2026

Uh oh!

github-actions Bot commented Jun 18, 2026

🛠️ [QUALITY] Cross-compiler resolution block copy-pasted 3 times

💡 [NITPICK] Inconsistent fallback style for toolchain check

💡 [NITPICK] Missing blank line before QUIC modules_prepare echo

Uh oh!

Uh oh!

Reviewers

Assignees

Labels

Projects

Milestone

Development

Uh oh!

1 participant
